变压吸附氧气设备，采用优质沸石分子筛为吸附剂，利用压吸附原理，直接从压缩空气中获得氮气。

KHO series pressure swing adsorptionOxygen generator uses high-qualityzeolite molecular sieve as adsorbent and pressure adsorption principle to obtaindirectly oxygen  gas from compressed air.

工作原理 Working Principle

压缩空气经空气净化系统除去油、水、固体尘埃等杂质后进入装有沸石子筛的吸附塔，空气中氮气、二氧化碳、水蒸汽等被分子筛大量吸附，而氧气因为扩散速率大而穿过吸附剂而实现分离。当吸附塔内吸附的氮等杂质达到一定程度后，降低压力使沸石分子解吸，使吸附剂再生，得以重复循环使用。

采用两个吸附塔在PLC的控制下循环工作，连续产出高品质氧气。

After the impurities such as oil, water and solid dust etc. are removed by the air purification system, the compressed air enters the adsorption tower equipped withzeolite molecular sieve . Nitrogen, carbon dioxide and water vapor etc. in the air are largely adsorbed by molecular sieve, while oxygen is separated through the adsorbent due to the high diffusion rate. When the nitrogen and other impurities adsorbed in the adsorption tower reach a certain degree, reducing the pressure makes thezeolite molecular sieve desorption, regeneration of the adsorbent, and reuse.

Two adsorption towers are used under the control of PLC to produce high quality oxygen gas continuously.

技术特点 TechnicalCharacteristics

完善的流程设计，*优使用效果。采用制氧新工艺，不断优化装置设计，降低能耗和本设备投资。操作简便，运行稳定，自动化程度高，可以实现无人运行。特有的分子筛保护装置，延长沸石分子筛的使用寿命。自动连锁的氧气排空装置，保证氧气产品质量。

可以选配氧气流量，纯度自动调节系统，远程监控系统等。

Perfect process design, optimal use effect. Adopt the new process of oxygen production, continuously optimize the device design, and reduce the energy consumption in the equipment  investment. Simple operation, stable operation, high degree of automation, can realize unmanned operation. The special molecular sieve protection device extends the service life of the zeolite molecular sieve. Automatic interlocking oxygen emptying device ensures the quality of oxygengas.

Optional oxygen flow, purity automatic control system, remote monitoring system, etc.

技术指标Technical Index

◎氧气流量:5～200Nm3/h     ◎氧气纯度:90～93％

◎氧气压力:0～0.4Mpa          ◎:≤-45℃(常压下)

◎Oxygen gas capacity:5～200Nm3/h     ◎Oxygen gas purity:90～93％

◎Oxygen gas Outlet Pressure:0～0.4Mpa ◎Oxygen gas Dew Point:≤-45℃(Under Normal Pressure )
